Dimensions (mm) : 105 x 146 x 70 mm
Weight : 418g
Voltage/Current: 5 VDC +/-10% @ 500 mA
Light Source: Illumination: 650nm RED LED
Print Contrast : 25% minimum reflective difference
Motion Tolerances : Upto 600 cm per second
Interfaces Support : USB, RS232, Virtual COM
Image (Pixels) : 752 pixels (H) x 480 pixels (V)
Minimum Resolution : 4 mil Code39
Symbology Decode Capability :
- 1D : UPC, EAN , Code128, Code 39, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc.
- 2D : PDF417, MicroPDF417, Data Matrix, Maxicode, QR code, MicroQR, Aztec, Hanxin, etc.
Humidity : 0% to 95% relative humidity, non-condensing
Drop Specifications : Designed to withstand 1.5m (5') drops
Ambient Light Immunity : 100,000 Lux
Decode Ranges :
Code 39 (5mil) : 0mm - 60mm
100% UPCA (13mil) - 0mm-200mm
