Dimensions (mm) : 151 x 141 x 93 mm
Weight : 595g
Voltage/Current: 5 VDC +/-10% @ 500 mA
Light Source : 617nm RED LED
Motion Tolerances : Max. 6m/s
Interfaces Supported : USB, RS232, Virtual COM
Image (Pixels) : 1280 (H) x 1080 (V)
Symbology Decode Capability :
- 1D : UPC, EAN , Code128, Code 39, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc.
- 2D : PDF417, MicroPDF417, Data Matrix, Maxicode, QR code, MicroQR, Aztec, Hanxin, etc.
Humidity : 0% to 95% relative humidity, non-condensing
Drop Specifications : Withstands 1.2m drop to concrete
Ambient Light Immunity : 100,000 Lux
Decode Ranges:
- Code 39 (3mil) : 5mm - 30mm
- Code 39 (5mil) : 0mm-100mm
- 100% UPCA (13mil) : 0mm-220mm
- PDF417 (6.88mil) : 0mm-150mm
- QR (20mil) : 0mm-240mm
