Dimensions (mm): 103x50x29
Weight: 162g
Battery capacity: 2500mAh
Light Source: Aiming: 617 nm,
LED illumination: 3500K white LED
Print Contrast: 25% minimum reflective difference
Motion Tolerances: Upto 25 inch (63.5 cm) per second
Identifiable Electronic Sreen Brightness: 30% and above
Images (Pixels): 640 pixels (H) x 480 pixels (V)
Symbology Decode Capability:
- 1D: UPC, EAN , Code128, Code 39, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc.
- 2D: PDF417, MicroPDF417, Data Matrix, Maxicode, QR code, MicroQR, Aztec, Hanxin, etc.
Humidity: 5% to 95%, Non-condensing
Drop Specifications: Withstand 1.5m drops to concrete
Ambient Light Immunity:
- Immune to normal indoor lighting up to 1600 Lux.
- Immune to sunlight up to 86,000 Lux.
Decode Ranges:
- Code 39 (3.13 mil): 65mm-105mm
- Code 39 (5.13 mil): 60mm-155mm
- UPC-A (13.3 mil): 50mm-330mm
- PDF417 (6.88 mil): 35mm-170mm
- DataMatrix (10 mil): 35mm-190mm
- QR (20 mil): 25mm-300mm
