Dimensions (mm): 188x90x70
Weight: 165g
Voltage/Current: 5 VDC +/-10% @ 500 mA
Light Source: Aimer: 525nm Green LED; illumination: 3500K white LED; Good Read: 525nm blue LED
Print Contrast: 25% minimum reflective difference
Motion Tolerances/Scanning Rate: Upto 2 Meter per second
Interfaces support: USB, RS232, Virtual COM
Image (pixels): 640 pixels (H) x 480 pixels (V)
Symbology Decode Capability:
- 1D : UPC, EAN , Code128, Code 39, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc.
- 2D : PDF417, MicroPDF417, Data Matrix, Maxicode, QR code, MicroQR, Aztec, Hanxin, etc.
Protection Level: IP65
Humidity: 5% to 95%, Non-condensing
Shock Specifications: Withstands multiple 1.8m (6ft.) drops to concrete
Ambient Light Immunity: Immune to normal indoor lighting up to 1600 Lux
Immune to sunlight up to 86,000 Lux
Decode Ranges :
- Code 39 (3.13 mil) : 50mm-70mm
- Code 39 (5.13 mil) : 25mm-180mm
- UPC-A 100% (13 mil) : 40mm-380mm
- PDF417 (6.88 mil) : 30mm-190mm
- Data Matrix (10 mil) : 20mm-80mm
- QR (20 mil) : 0mm-320mm
