- Scanning Technology: Area-Imaging
- Decode Capability:
- 1D : UPC, EAN , Code128, Code 39, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Codabar, MSI Plessey, GS1 DataBar, China Postal, Korean Postal, etc.
- 2D : PDF417, MicroPDF417, Data Matrix, Maxicode, QR code, MicroQR, Aztec, Hanxin, etc.
- Light Source : 100,000 Lux
- Aimer: 617nm LED; illumination: 6500K LED
- Voltage/Current: 5 VDC +/-10% @ 500 mA
- Print Contrast: 25% minimum reflective difference
- Interface Support: Bluetooth, USB, Virtual COM
- Image (pixels): 640 pixels (H) x 480 pixels (V)
- Humidity: Relative humidity 0%-95%, no condensation
- Shock Specifications: Designed to withstand 1.5m (5') drops
- Decode Ranges:
- 1D Minimal Resolution : 4mil
- Code 39 (5mil) : 30mm-90mm
- 100% UPC-A (13 mil) : 40mm-170mm
- Dimensions (mm) : 75 x 83 x 70 mm
- Weight : 120g
